Material Polycrystalline Silicon Size 1195mmSZX541mmX30mm
Number of Cells 36(4X9)
Max. Power 90Wp
Open-circuit voltage (Voc) 22.2V
Optimum operating voltage (Vmp) 19.4V
Short-circuit current (Isc) 5.72A
Optimum operating current (Imp) 4.88A
Operating temperature -40 ? to 85 ?
Maximum system voltage 715VDC
Cable LAPP 4.0m ?
Cable Length 750mm (negative) and 750mm (positive)
Terminal MC Plug Type IV
