Size:260*300*780mm(L*W*H)Weight:80KG
Power Source: Single Phase 220VAC/ 50/60HZ,10A
Total Power:550W
Cylinder Pressure:0.4-0.7MPa(adjustable)
Working Efficiency: 12000 crimps/hour(cauculated as 12Pins above ribbon cable)
Appropriate Wire: 0.8-2.0mm,AWG20-28,
Red Blue White FBC(2468),Grey FBC(2651),Color FBC and etc 2-40pins
Cutting Length:>70mm
Ribbon Cable Split Length: 30mm
Crimping Strength: 1.5T
